BIQU H2 V2S Lite Extruder

SKU: 1060000581

$66.21 $92.00 Save $25.79

Shipping calculated at checkout

H2 V2S Lite Extruder Complete Kit
Only Nozzle (1.75/0.6mm)
Only Heating Block
Only Throat Tube
Only MicroProbe
Other Brass Nozzle (1.75/0.4mm)
Other Hardened Steel Nozzle (1.75/0.4mm)
Other Hardened Steel Nozzle (1.75/0.6mm)
NOTIFY ME WHEN IN STOCK
2022 09 06t114842

Global shipping

180-days warranty

7-days refund

What Are The Surprises?

11.11 DOUBLE ELEVEN

Time is 11/01 - 11/11 PDT. The biggest discount event of this year.

3D Printer
Module Board
Filament
Upgrade Tool
Buy X Get Y

BLACK FRIDAY

Time is 11/20 - 11/26 PDT. The biggest discount event of this year.

Motherboard
Extruder
Driver Board
Screen
Buy X Get Y

Code is

Coming soon

Limited 300

Code is

Coming soon

Limited 100

Code is

Coming soon

Limited 100

Code is

Coming soon

Limited 50

Buy more than $1000, Get for Gifts

Over $1000, get a BL Touch

Over $1500, get a TFT35 E3 V3.0

Top 3 reward a MicroProbe

Wheel Game to Win Prizes

Free 3D printer, 90% off coupon...

Coming soon

>> EASTER SEASON SALE <<

The biggest deal of 3D printers | Join the printing contest to win prizes | Surprising group buy price

Product Description

Lighter and Better Heat Dissipation

Featuring a hollow-out design with a visible inner structure, H2 V2S Lite weighs only 175g, which contributes to less inertia and more accurate positioning.

Rapid Cooling

At the same time, the airflow is also improved to give better heat dissipation. Plus the heatsink and fan, H2 V2S Lite realizes a highly effective cooling.

Higher Flow. Faster Printing

Using a 0.6mm brass nozzle, and a longer heater block, H2 V2S Lite can output 45mm³/s to meet faster printing needs.

Labor-Saving Lever

The upgraded lever, a labor-saving and convenient design, eliminates the need to continuously hold the handle when inserting or removing filament.

Quick Detach Heat Break

Now, with the quick detach design, you are allowed to remove the heat break by simply using a hex key,making maintaining much easier and more convenient.

Dual Gear Feeding

Featuring a dual-gear system to provide an exceptional pushing force, ensuring smooth feeding and giving snappy retractions.

Adjustable Filament Loading Tension

Simply rotate the tension screw to accommodate different filaments, improving the printing success rate.

Wide Compatibility

It can collaborate with BIQU B1, BIQU BX Ender-3, Voron 2.4, Voron V0, and Vzbot.

What's in the Box

It includes an extruder, user manual, cooling fan, cables, screws and so on.

Details Make Perfect - Aluminium Alloy Case Crafted from aluminium alloy H2 V2S Lite is made for high durability,high strength,corrosion resistance, and above all, lightweight.

Filament Drive Gear - Made of tool steel plated with nano-coating to improve hardness wear resistance,corrosion resistance and provides longer life when printing abrasive materials.

Idler Arm - Made of 7075 T6 aluminum, with special blend high-performance anti-wear Mos2 grease to improve the quick release lever hap tics and enhance wear resistance.

Heat Break - H2 bi-metal(copper alloy + grade 5 titanium alloy). High performance thermal grease has been pre-applied to the heat break to increase thermal conductivity between the heat break and heat sink to improve cooling performance

More Mounting Holes - 4 screw mounting holes are available for installing an auto leveling sensor cooling tan.

(Note: The nozzle is custom-made and will be released in the near future.)

Dimensions & Specs

Extrusion Method

Dual Gear Extrusion

Maximum Printing Temperature

270℃

Weight

175g (including Heater Cartridge, Thermistor, and Fan)

Maximum Extrusion Force

7.5kg (depending on the filament)

Extrusion (based on the existing)

2700mm3/min (depending on the filaments)

E-step

932/mm at 16 microstep (Further calibration is recommended)

Klipper Rotation Distance

3.433

Recommended Motor Current

800mA

Gear Ratio

7:1

Drive Gear Circumference

24.5mm

Filament Diameter and Tolerance

1.75±0.05mm

Thermistor Type

NTC100K

Heater Cartridge Power

70W

Heater Cartridge Voltage

24V

*Note: Not compatible with standard NEMA14 motor.

Quick View Relavant Files

Customer Reviews

Based on 13 reviews
46%
(6)
38%
(5)
15%
(2)
0%
(0)
0%
(0)
P
Peter Jervis Battilega
Value for money impressive build quality

The H2 Vs light is ver well constructed for the money. Parts appear interchangeable with other H2 extenders . The heat block is a bit strange I have not tested its performance but would probably switch this out for a high temp compatible heat block so I can use more standard type m6 nozzle . Love the additional changes to the filament extruded that make adjusting tension possible

P
P.M.
Mostly awesome

The H2 V2S light overall is an impressive direct drive extruder. It's easy to set up, prints beautifully, and looks amazing. My only complaint is that there is fastening screw to hold the heater cartridge in place. It does stay put and doesn't seem to effect printing, but it would be more reassuring to have the heater sit more securely in its hole. Otherwise I am very happy with the product and its quality.

P
Peter Harnisch
Sexiest hotend i've owned.

I recieved it today, and it's by far the sexiest hotend I've owned. I have not installed it yet. I see that the heatbreak is probably replaceable by the heatbreak of the standard h2. However, it would lose some of it's sexyness. So I am too waiting for the other nozzles. Please also create the strong nozzles (hardened steel or whatever).

S
Sonal Diwakar

BIQU H2 V2S Lite Extruder

W
Wouter Dobbenberg
No nozzles available!?

so I bought the biqu lite for its weight reduction. when installing I noticed the weird nozzle, than came to figure out that there are no alternatives to the stock nozzle! So I was wondering, is it possible to attach the revo hot end and nozzle to the biqu lite model?

Hello, we are sorry that the Revo nozzle doesn't match with the Lite extrude. We will shelf the customized Lite nozzle soon, please be patient. Thank you.
